Sticking Profiles

Sticking Profiles

Take a look at our sticking profiles below. If you need to match a profile for a historical renovation or you have your own profile design that you want us to create, we can make a custom cutter to get your job done.

Click here for the sticking profiles key.

•

  8000

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  Varies	Varies	Varies	Varies

  Dimensions:

  A	B
  Varies	Varies

  True Divided Lite Mullion Width:

  1 1/2"
•

  8001

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  	1/2"	3/4"	1 1/2"

  Dimensions:

  A	B
  5/8" - 3/4"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8002

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  1/4"

  Dimensions:

  A	B
  9/16"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8003

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  		3/4"	1 1/2"

  Dimensions:

  A	B
  3/4"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8004

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  	1/2"

  Dimensions:

  A	B
  5/8"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8005

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  1/4"

  Dimensions:

  A	B
  9/16"	7/16"

  True Divided Lite Mullion Width:

  1 3/8"
•

  8006

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  	1/2"	3/4"	1 1/2"

  Dimensions:

  A	B
  5/8" - 3/4"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8007

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  	1/2"	1"

  Dimensions:

  A	B
  5/8"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8009

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  1 3/8"	1 3/4"	2 1/4"

  Dimensions:

  A	B
  5/8" - 7/8"	1/4"

  True Divided Lite Mullion Width:

  1"
•

  8010

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  	1/2"	3/4"	1 1/2"

  Dimensions:

  A	B
  5/8" - 3/4"	5/8"

  True Divided Lite Mullion Width:

  1 3/4"
•

  8011

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  1/4"	1/2"	1"

  Dimensions:

  A	B
  9/16" - 5/8"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8012

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  	1/4" - 3/4"

  Dimensions:

  A	B
  1/2" - 3/4"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8013

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  	1/2"

  Dimensions:

  A	B
  5/8"	5/8"

  True Divided Lite Mullion Width:

  1 3/4"
•

  8014

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  		3/4"

  Dimensions:

  A	B
  3/4"	1 1/8"

  True Divided Lite Mullion Width:

  2 3/4"
•

  8015

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  1/4"

  Dimensions:

  A	B
  9/16"	3/8"

  True Divided Lite Mullion Width:

  1 1/4"
•

  8016

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  1/4"	1/4" - 1/2"	1/2" - 1"	1" - 1 3/4"

  Dimensions:

  A	B
  5/8"	1/2"

  True Divided Lite Mullion Width:

  1 1/2"
•

  8017

  Available Door Thicknesses:

  1 3/8"	1 3/4"	2 1/4"	3"

  Rabbet Width:

  1 3/8"	1 3/4"	2 1/4"	3"
  1/4" - 3/8"	1/2" - 3/4"	3/4" - 1 1/4"	1 1/2" - 2"

  Dimensions:

  A	B
  1/2"	1/4"

  True Divided Lite Mullion Width:

  1 1/2"
